TECHNICAL DETAILS (1.5HP X 3PH)

Suction: 38 MM (As Per Requirements)
Discharge: 38 MM (As Per Requirements)
Connection Type: SMS Union / Tcl And / Flange
Product Wetted Parts MOC: AISI 304/316
Other Parts MOC: All Parts In SS 304
Seal Type: Single Mechanical Shaft Seal
Seal Combination: TC/TC/V, SIC/SIC/V, SS/C/V
Impeller Type: Open Type (dynamically Balanced)
Motor Make: Any Reputed
Motor Drive Detail: 1.5 Hp (2900 Rpm) 3 Phase / 1 phase Foot Cum Flange
Volt- 415 V / 230 V , Motor Insulation ‘f’ Class, Frequency 50 Hz, Ip-55
Pole: 2 Poles
Finish: Surface Polished 180 Grit
Mounting: SS Leg With Adjustable Ball Feet With Ss Shroud
