TECHNICAL DETAILS (10HP X 3PH)

Suction: 63 MM (As Per Requirements)
Discharge: 63 MM (As Per Requirements)
Connection Type: SMS Union / Tcl END/ Flange END
Product Wetted Parts MOC: AISI 316
Other Parts MOC: All Parts In SS 304
Seal Type: Single Mechanical Shaft Seal / Double Mechanical Shaft Seal
Seal Combination: TC/TC/V, SIC/SIC/V, SS/C/V
Impeller Type: Open Type (dynamically Balanced)
Motor Make: Any Reputed
Motor Drive Detail: 10 Hp (2900 Rpm) 3 Phase, Foot Cum Flange, Volt- 415 V + 10%  Motor Insulation ‘f’ Class, Frequency 50 Hz, Ip-55
Pole: 2 Poles
Finish: Product Content Surface Polished 180 Grit
Mounting: SS Leg With Adjustable Ball Feet With SS Shroud
